ETHERLINE® MARINE FRNC FC CAT.5 2x2xAWG22
Supplier-ID: 2170889
Description
Shipbuilding, Wiring machines, devices, and control cabinets, suitable for EtherCAT and EtherNet/IP applications, Onshore and offshore applications, max. cable length for 100 Mbit/s is 85 m, Can be used for Industrial Ethernet in harsh industrial environments, For use in dry, damp and wet rooms, Premium screening against electromagnetic interference, 2-pair: 10/100 Mbit/s for Industrial Ethernet, Fine-wire strand made of tin-plated copper wires, Colour-coded in accordance with PROFINET for Cat.5 applications, Star quad, Inner sheath: Thermoplastic copolymer (FRNC), SF/UTP: Braid of tin-plated copper wire and laminated aluminium foil as overall shielding, Halogen-free and flame-retardant FRNC outer sheath, Colour: green (similar to RAL 6018), CMG UL/CSA certification 75°C or PLTC, Sun Res, Flame-retardant according to CSA FT4 UL Vertical-Tray Flame Test, Highly flame-retardant in accordance with IEC 60332-3 and FT4, CAT.5 performance, Fast Connect (FC) cable design,
| Specification | Value |
|---|---|
| Core insulation | Polypropylene |
| Core identification | Colour |
| Colour outer sheath | Green |
| Material outer sheath | Other |
| Conductor category | Class 2 = stranded |
| Operating temperature, fix | -25 - 70 |
| Number of cores | 4 |
| Outer diameter approx. | 6,5 |
| Low smoke (acc. EN 61034-2) | No |
| Stranding element | Quad |
| Screen over stranding element | None |
| Screen over stranding | Foil + braiding |
| Conductor material | Cu, tinned |
| AWG-size | 22 |
| Category | 5 |
Product images
Datasheet
Here you can download the product's datasheet.
Download datasheetPreise
| Amount | Netto | Brutto |
|---|---|---|
| 100m | 1.219,38€ | 1.451,06€ |
| 500m | 5.698,52€ | 6.781,24€ |
| 1000m | 10.919,00€ | 12.993,62€ |
Price calculation
Below you can calculate the total price (including copper surcharge) for your desired cable length. Please note, that the copper surcharge will depend on the current stock exchange rate (today: 891,00€/100kg).
For further information regarding the shipment or mass-discounts you can contact us. Please note, that will charge an additional 15,00€ for cutting if you order less than 100 meters or other non-standard sizes.
For orders of less than 150,00€ product value we will charge a fee of 25,00€. Purchase on account - a credit check may be required. All Lapp products will be shipped free of charge within Germany for orders of 350,00€ or more
